Strong Anti-drop Capability Single Reconnaissance Robot Thrower Robot Forced Booting

Minimum Order Quantity : 1set Price : USD9000
Packaging Details : Aluminium case Delivery Time : 60days
Payment Terms : T/T Supply Ability : 10sets/month
Place of Origin: China Brand Name: Topsky
Model Number: T32

Detail Information

Total Length: 249mm Weight: 1.25kg
Speed: 1.2m/s Power: ≥74kw
Climbing Ability: 57.74% Ditch Crossing Width: 90mm
Obstacle Overcoming Height: 35mm Deviation During Straight Running: 0.3%

Product Description

Thrower Robot



I. Product Overview

The Forest Isolation Belt Development Vehicle is composed of an isolation belt development machine module, large blunt blade cutting module, heavy-duty forest grab bucket, bucket, quick-change mechanism, tracked walking mechanism, arm lifting device, cab, electrical hydraulic system, and wireless remote control. The equipment a double triangular crawler walking mechanism, capable of constructing fire barriers by crushing combustible vegetation (trees, shrubs, grass) in dense forests, shrublands, and grasslands. It can crush trees with diameters ≥250mm (≥80mm for continuous crushing) and has no height restrictions on vegetation. Primary applications include establishing fire isolation zones, maintaining fire escape routes, creating temporary rescue passages, setting up safety islands, assisting in fire scene cleanup, and constructing soil isolation zones in mountainous forest areas.



III. Product Features

  1. Strong Anti-drop Capability
    • Capable of being thrown from high altitudes and across buildings, excelling in anti-drop performance.
    • High vertical throwing distance, enabling it to reach the designated operation area in the shortest time.
    • Long horizontal throwing distance, effectively saving response time and gaining the initiative in operations.
  2. Intelligent Remote Controller
    • Multi-functional expansion buttons with one-key response for convenient operation.
    • Cruise control function can be activated with one key, freeing your hands to the greatest extent.
    • Assisting in coordinated operations, it can act as a vanguard under speed maintenance.
  3. Excellent Slope Climbing Performance
    • Can climb slopes that electric scooters can climb, and even those that electric scooters can't.
    • Powerful driving force, fast driving speed on slopes (on concrete roads).
  4. Fast Driving Speed
    • Equipped with dual DC brushless motors for flexible driving on flat ground and slopes.
    • In the fast mode, it can walk side by side with people.
  5. Forced Booting
    • With infrared night vision function, it is not easily detectable in dark environments, ensuring safe operation.
    • Hidden sound pickup function, which can normally feedback voice information even when the robot is fully shielded.
    • It won't be easily shut down and damaged, maintaining smooth data feedback and no disconnection.
  6. Independent Antenna
    • Simple appearance, facilitating passage through complex road surfaces.
    • Soft-body design, not easily damaged when thrown on flat ground or from high altitudes.
  7. Unique Front Face
    • Badge-style design symbolizes honor.
    • Equipped with multiple LED lights. The constant light can illuminate the front, and the stroboscopic light represents warning, deterrence, and majesty.

IV. Main Technical Indicators




  1. Name: Thrower Robot
  2. Model: T32-V3.0
  3. Basic Functions: Throwing, audio and video reconnaissance, cruise control reconnaissance, etc.
  4. Power: Electric, ternary lithium battery
  5. Dimensions: ≤ Total length 249mm × Wheel diameter 100mm, Balancing tail length 170mm
  6. Turning Diameter: Rotation in place
  7. Weight: ≤ 1.25kg
  8. Maximum Linear Speed: ≥ 1.2m/s, stepless speed regulation under remote control
  9. Anti-fall Performance: Thrown vertically from 12m and horizontally from 30m (This parameter is consistent with the test report issued by the Quality Inspection Center for Security and Police Electronic Products of the Ministry of Public Security)
  10. Deviation during Straight Running: ≤ 0.3%
  11. Slope Climbing Ability: ≥ 57.74% (or 30°)
  12. Obstacle Overcoming Height: ≥ 35mm
  13. Ditch Crossing Width: 90mm
  14. Video Pixel: 1080*800
  15. Continuous Walking Time: 2h
  16. Reliability Working Time: Passed the 24-hour continuous stability and reliability test
  17. Remote Control Distance: > 120m (Outdoors) (This parameter is consistent with the test report issued by the Quality Inspection Center for Security and Police Electronic Products of the Ministry of Public Security)
  18. Remote Control Distance (Suitable for Shielded Scenarios): > 30m (Indoors) (This parameter is consistent with the test report issued by the Quality Inspection Center for Security and Police Electronic Products of the Ministry of Public Security)
  19. Cruise Control: Operating the joystick in any direction and holding it for ≥ 6 s, the robot will maintain its current speed. During the mission, it can achieve the effect of coordinated progress.
  20. Front Shock Absorption: The rubber shock-absorbing wheels adopt an end-face shock absorption and hollow design, with multi-angle shock resistance capabilities in horizontal, vertical, and inclined directions. At the same time, the rubber wheels adopt a wide cross-section design, which also has certain passability on sandy roads.
  21. Intelligent Booting: It has the function of automatically turning on after being thrown and landing.
  22. Wheel-type Balancing Tail (Optional): It has a unique appearance and can reduce walking friction and noise.
  23. Speed-up Shoe Covers (Optional): Can improve the passability on sandy roads and the maximum linear driving speed.
  24. Control Terminal: Handheld integrated graphic and digital remote control terminal

2 Robot Video and Audio Sensing

  1. Quantity and Configuration of Cameras: The video system consists of 1 fixed high-definition infrared camera on the robot body, providing a forward viewing image. It can provide clear images under a low illuminance of 0.01LUX. The camera should be able to effectively and clearly collect the on-site situation even under zero illuminance and display it on the liquid crystal screen of the operation terminal.
  2. Camera Pixel: Million high-definition images, with a resolution of 1080P and a wide-angle of 60°.
  3. Camera Protection Level: IP66
  4. Sound Collection Technical Requirements: It can remotely collect on-site sounds to facilitate understanding of the situation of trapped people. The sound pickup distance of the microphone is ≤ 5 meters, the frequency range is 20Hz~20kHz, and the sensitivity is ≥ 40dB.
