High Efficiencyhydraulic Spreader Tool Hydraulic Cutter Spreader 680mm Opening Distance
Contact Person : Yang
Phone Number : +8618010030825
WhatsApp : +8613436381865
| Minimum Order Quantity : | 1set | Price : | USD1800 |
|---|---|---|---|
| Packaging Details : | Aluminium case | Delivery Time : | 60days |
| Payment Terms : | T/T | Supply Ability : | 10sets/month |
| Place of Origin: | China | Brand Name: | Topsky |
|---|---|---|---|
| Model Number: | GYJK-38-60/33(25) |
|
Detail Information |
|||
| Size: | 839 *267 *212mm | Weight: | 13.7kg |
|---|---|---|---|
| Operating Pressure: | 75MPa | Expansion Force: | 59.6kN |
| Expansion Distance: | 370mm | No-load Closing And Opening Time: | 9.2 S |
| Highlight: | 72Mpa Hydraulic Combi-tool,Single Tube Hydraulic Combi-tool |
||
Product Description
|
Testing basis:
Test Outline for Hydraulic Demolition Tools GB/T 17906-2021 General Technical Conditions for Hydraulic Demolition Tools of Fire Emergency Rescue Equipment GB/T 7999-2015 Method for Optical Emission Spectrometric Analysis of Aluminium and Aluminium Alloys by Direct Reading
Operating pressure: 75MPa
Expansion force: 59.6kN Expansion distance: 370mm Shearing capacity: Capable of cutting a round steel with a diameter of 30mm (made of Q235A material) at one time. No-load closing and opening time: 9.2s Mass: 13.7kg External dimensions: Length * Width * Height: 839mm * 267mm * 212mm
After the demolition tool undergoes a strength test at 1.5 times the rated operating pressure, there should be no persistent hydraulic oil leakage, visible permanent deformation, fracture, or mechanical damage.
After the sealing test, the maximum displacement is 1mm. After the tests at a high temperature of 55℃ and a low temperature of -30℃, it can work normally without leakage or abnormal phenomena. After the vibration test, the operation is normal without abnormal phenomena. The manual directional valve of the demolition tool has the function of automatically returning to the neutral position. During the operation process, when the manual control directional valve returns to the neutral position, the demolition tool stops operating within 2s. When it operates again, the demolition tool does not move in the reverse direction. During the operation process, if the power supply is interrupted, the cutter spreader has a self-locking performance, and its maximum displacement should be 1.4mm. After the reliability test, the operation should be normal without leakage or abnormal phenomena. There should be no curling or chipping of the cutting edges of the cutter spreader. Test of the cylinder material (7075) Si: 0.21% Fe: 0.45% Cu: 1.3% Mn: 0.12% Mg: 2.4% Cr: 0.19% Zn: 5.4% Ti: 0.04% |
Beijing Topsky Intelligent equipment Group Co.,Ltd.. (stock code: 836307) was founded in 2003, committed to making the world safer with innovative equipment, and determined to become a continuous leader in global high-end safety equipment.
Our company has independent R&D and technology promotion capabilities, and has one R&D and production building. Headquartered in Jinqiao Industrial Base, Zhongguancun High-tech Park, it is a national high-tech enterprise with a registered capital of RMB 46,514,300. Our company has independent R&D and manufacturing capabilities. Located in Beijing Economic Development Zone, the 3-story R&D building covers an area of 1,500 square meters, the production building is 1,800 square meters, and the third-phase production building is nearly 3,000 square meters under construction.
Our innovative technologies, services and systems are dedicated to serving the firefighting, law enforcement agencies, safety supervision bureaus, coal mines, petrochemicals, and armed police in many fields. It involves the research and development of high-end equipment such as drones, robots, unmanned ships, special equipment, emergency rescue equipment, law enforcement equipment, and coal mine equipment.
So far, many products have been exported to more than 10 countries.
1 Q:Do you have any discount?
A:Yes, if you buy large QTY, please send us a email, we will give you a big discount.
2 Q:What's the delivery time?
A:According to the specification and quantity of your order, generally 10-15 days for normal
standard products within 50pcs.
3 Q:Do you have overseas distributor?
A:Yes,we have distributors in Korea, Singapore, Malaysia, UK, Iran, India and so on.
4 Q:Can we use our logo on the products?
A:Yes.We can provide OEM and sign a licensing agreement.
5 Q:Are you manufacturer or trading company?
A:We are manufacturer with 18 years of experience.Welcome to visit our company.
6 Q:What's the means of transport?
A:Express such as TNT,Fedex,DHL,UPS, or logistics by indicator.
7: Why we should choose your company?
We have many years of industry production and management experience, professional R & D, sales, after-sales team. It can
perfectly solve all the problems that customers encounter from purchase to sale.
8: How to cooperate with you?
You only need to contact our business representative, and they will be patient to guide you through the whole process
9: What's your payment way?
T/T by our bank account directly.
